Vibrating Screen Manufacturers

KINGSON’S vibrating screen, with a circular motion, is a two bearing free floating vibrating screen which proficiently screens all moderately free-flowing material. The circular throw action is delivered from uneven weights which are attached to the ends of the screening surfaces and ensure that the material travels over the screening surfaces at a constant rate. The amplitude or degree of vibration can be acclimated to fit a difference in obligation by adding a subtracting balance weight plate. The circular motion ensures rapid strait. The yield of the screen relies upon screen tendency; taking care of technique, screen RPM and vibration.We undertake all ranges of vibrating screens as per the capacity of plant and choices of the clients.

Vibrating Screen Manufacturers

Key Features:
● Sharp sized end products with higher capacity and lower costs. New technology equipped with two bearings and grease lubrication.
● Frames are of rugged construction with torsionally rigid tubular cross members.
● Perfect circle throw can be adjusted by adding or removing counterweights, discharging bulky goods, gravel, sand, coal ores and coke from hoppers.

S.NO. MODEL NO. OF DECK SCREEN AREA
(SQ MTR)		 SCREEN CAPACITY (TPH) DRIVE HP  RPM APPROX WEIGHT
(IN TON)
1 KVS84 1 2.97 12-19 5 850-1000 1.50
2 KVS104 3.5 3.72 20-29 7.5 850-1000 1.80
3 KVS124 3.5 4.45 30.39 10 850-1000 2.32
4 KVS125 3.5 5.57 40-59 12.5 850-1000 2.92
5 KVS145 3.5 6.5 60-69 15 850-1000 3.01
6 KVS165 3.5 7.43 70-79 15 850-1000 3.94
7 KVS185 3.5 8.36 80-99 20 850-1000 5.36
8 KVS205 3.5 9.29 100-124 20 850-1000 6.77
9 KVS206 3.5 11.15 125-149 25 850-1000 7.30
10 KVS246 3.5 13.38 149-200 30 850-950 8.93
HEAVY DUTY SCREENS
11 KVS1606 1-4 9 150-250 30 850-1000 10-12.5
12 KVS206 1-4 11 200-400 30-40 850-1000 11-13.5
13 KVS246 1-3 13 300-600 30X2 850-1000 12-14
14 KVS247 1-3 15.6 350-650 30X2 850-1000 13-15
15 KVS248 1-2 17.6 400-700 40X2 850-1000 13-15
